112
"B" Group: Fine Tuning Functions Section 3-6
Frequency conversion coefficient setting: b086 – By setting b086, con-
verted output frequency is monitored in d007. (d007 = d001 x b086)
Frequency set in monitoring: b163 – If 01 is set in b163, frequency can be
changed by up/down key in monitor display d001 and d007.
Action selection in case of external operator disconnection: b165 –
When an external operator is disconnected, the inverter behaves according to
b165 setting.
Note If the power is off with displaying "000" after the set, b038 comes when power
is on again.
"B" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
b038 Initial display selection 000 Func. code that key
pressed last displayed.(*)
001~030 d001~d030 displayed
201 F001 displayed
202 B display of LCD operator
8 001 –
B086 Frequency scaling conversion
factor
Specify a constant to scale the
displayed frequency for D007 mon-
itor, range is 0.01 to 99.99
8 1.00 –
b150 Display ex.operator connected When an external operator is con-
nected via RS-422 port, the built-
in display is locked and shows
only one "d" parameter configured
in:
d001 ~ d030
8 001 –
b160 1
st
parameter of Dual Monitor Set any two "d" parameters in
b160 and b161, then they can be
monitored in d050. The two
parameters are switched by up/
down keys.
Set range: d001 ~ d030
8 001 –
b161 2
nd
parameter of Dual Monitor 8 002 –
b163 Frequency set in monitoring Two option codes:
00 Freq. set disabled
01 Freq. set enabled
9 00
b164 Automatic return to the initial
display
10 min. after the last key opera-
tion, display returns to the initial
parameter set by b038. Two option
codes:
00 Disable
01 Enable
9 00
b165 Ex. operator com. loss action Five option codes:
00 Tr ip
01 Trip after deceleration to a
stop
02 Ignore
03 Coasting (FRS)
04 Decelerates to a stop
9 02
