Omron MX2 - Step-by-Step Basic Installation

5
MX2 Inverter Specifications Section 1-2
Item Three-phase 200V class Specifications
MX2 inverters, 200 V models A2001 A2002 A2004 A2007 A2015 A2022
Applica-
ble motor
size *2
kW VT 0.2 0.4 0.75 1.1 2.2 3.0
CT0.10.20.40.751.52.2
HPVT1/41/211.534
CT1/81/41/21 2 3
Rated
capacity
(kVA)
200 V VT 0.4 0.6 1.2 2.0 3.3 4.1
CT0.20.51.01.72.73.8
240 V VT 0.4 0.7 1.4 2.4 3.9 4.9
CT0.30.61.22.03.34.5
Rated input voltage Three-phase: 200 V-15% to 240 V+10%, 50/60 Hz±5%
Rated output voltage *3 Three-phase: 200 to 240 V (proportional to input voltage)
Rated output current
(A)
VT1.21.93.56.09.612.0
CT1.01.63.05.08.011.0
Starting torque *6 200% at 0.5 Hz
Braking Without resistor 100%: ≤50 Hz
50%: ≤60 Hz
70%: ≤50 Hz
50%: ≤60 Hz
With resistor 150%
DC braking Variable operating frequency, time, and braking force
Weight kg1.01.01.11.21.61.8
lb2.22.22.42.63.54.0
Item Three-phase 200V class Specifications
MX2 inverters, 200 V models A2037 A2055 A2075 A2110 A2150
Applica-
ble motor
size *2
kW VT 5.5 7.5 11 15 18.5
CT3.75.57.511 15
HPVT7.510152025
CT 5 7.5 10 15 20
Rated
capacity
(kVA)
200 V VT 6.7 10.3 13.8 19.3 20.7
CT 6.0 8.6 11.4 16.2 20.7
240 V VT 8.1 12.4 16.6 23.2 24.9
CT 7.2 10.3 13.7 19.5 24.9
Rated input voltage Single-phase: 200 V-15% to 240 V+10%, 50/60 Hz±5%
Rated output voltage *3 Three-phase: 200 to 240 V (proportional to input voltage)
Rated output current
(A)
VT 19.6 30.0 40.0 56.0 69.0
CT 17.5 25.0 33.0 47.0 60.0
Starting torque *6 200% at 0.5 Hz
Braking Without resistor 100%: ≤50 Hz
50%: ≤60 Hz
70%: ≤50 Hz
50%: ≤60 Hz
With resistor 150%
DC braking Variable operating frequency, time, and braking force
Weight kg 2.0 3.3 3.4 5.1 7.4
lb 4.4 7.3 7.5 11.2 16.3
