Omron MX2 - Parameter Group C

296
ModBus Data Listing Section B-4
Parameter group C
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1401h Input [1] function C001 R/W 0 (FW: Forward RUN), 1 (RV: Reverse
RUN), 2 (CF1: Multispeed 1 setting), 3
(CF2: Multispeed 2 setting), 4 (CF3: Mul-
tispeed 3 setting), 5 (CF4: Multispeed 4
setting), 6 (JG: Jogging), 7 (DB: external
DC braking), 8 (SET: Set 2nd motor data),
9 (2CH: 2-stage acceleration/decelera-
tion), 11 (FRS: free-run stop), 12 (EXT:
external trip), 13 (USP: unattended start
protection), 14: (CS: commercial power
source enable), 15 (SFT: software lock),
16 (AT: analog input voltage/current
select), 18 (RS: reset), 20 (STA: starting
by 3-wire input), 21 (STP: stopping by 3-
wire input), 22 (F/R: forward/reverse
switching by 3-wire input), 23 (PID: PID
disable), 24 (PIDC: PID reset, 27 (UP:
remote control UP function), 28 (DWN:
remote control DOWN function),
29 (UDC: remote control data clearing),
31 (OPE: forcible operation), 32 (SF1:
multispeed bit 1), 33 (SF2: multispeed bit
2), 34 (SF3: multispeed bit 3), 35 (SF4:
multispeed bit 4), 36 (SF5: multispeed bit
5), 37 (SF6: multispeed bit 6), 38 (SF7:
multispeed bit 7), 39 (OLR: overload
restriction selection), 40 (TL: torque limit
enable), 41 (TRQ1: torque limit selection
bit 1), 42 (TRQ2: torque limit selection bit
2), 44 (BOK: braking confirmation), 46
(LAC: LAD cancellation), 47 (PCLR:
clearance of position deviation), 50 (ADD:
trigger for frequency addition [A145]), 51
(F-TM: forcible-terminal operation), 52
(ATR: permission of torque command
input), 53 (KHC: cumulative power clear-
ance), 56 (MI1: general-purpose input 1),
57 (MI2: general-purpose input 2),
58 (MI3: general-purpose input 3), 59
(MI4: general-purpose input 4), 60 (MI5:
general-purpose input 5), 61 (MI6: gen-
eral-purpose input 6), 62 (MI7: general-
purpose input 7), 65 (AHD: analog com-
mand holding), 66 (CP1: multistage posi-
tion settings selection 1 ), 67 (CP2:
multistage position settings selection 2),
68 (CP3: multistage position settings
selection 3), 69 (ORL: Zero-return limit
function), 70 (ORG: Zero-return trigger
function), 73 (SPD: speed / position
switching), 77 (GS1: safety input 1), 78
(GS2: safety input 2), 81 (485: EzCOM),
82 (PRG: executing EzSQ program), 83
(HLD: retain output frequency), 84 (ROK:
permission of run command), 85 (EB:
Rotation direction detection(for V/f with
ENC), 86 (DISP: Display limitation), 255
(no: no assignment),
–
1402h Input [2] function C002 R/W –
1403h Input [3] function C003 R/W –
1404h Input [4] function C004 R/W –
1405h Input [5] function C005 R/W –
1406h Input [6] function C006 R/W –
1407h Input [7] function C007 R/W –
1408h to
140Ah
(Reserved) - - Inaccessible –
140Bh Input [1] active state C011 R/W 0 (NO), 1 (NC) –
140Ch Input [2] active state C012 R/W 0 (NO), 1 (NC) –
140Dh Input [3] active state C013 R/W 0 (NO), 1 (NC) –
140Eh Input [4] active state C014 R/W 0 (NO), 1 (NC) –
140Fh Input [5] active state C015 R/W 0 (NO), 1 (NC) –
1410h Input [6] active state C016 R/W 0 (NO), 1 (NC) –
