295
ModBus Data Listing Section B-4
1375h to
137Ah
(Reserved) – – – –
137Bh Brake Control Enable b120 R/W 0 (disabling), 1 (enabling) –
137Ch Brake Wait Time for Release b121 R/W 0 to 500 0.01 [sec.]
137Dh Brake Wait Time for Acceleration b122 R/W 0 to 500 0.01 [sec.]
137Eh Brake Wait Time for Stopping b123 R/W 0 to 500 0.01 [sec.]
137Fh Brake Wait Time for Confirma-
tion
b124 R/W 0 to 500 0.01 [sec.]
1380h Brake Release Frequency b125 R/W 0 to 40000 0.01 [Hz]
1381h Brake Release Current b126 R/W 0 to 2000 0.1 [%]
1382h Braking frequency b127 R/W 0 to 40000 0.01 [Hz]
1383h (Reserved) – – – –
1384h (Reserved) – – – –
1385h Deceleration overvoltage sup-
pression enable
b130 R/W 0 (disabling), 1 (enabling), 2 (enabling
with acceleration)
–
1386h Decel. overvolt. suppress level b131 R/W 200 V class: 330 to 390 (V)
400 V class: 660 to 780 (V)
1 [V]
1387h Decel. overvolt. suppress const. b132 R/W 10 to 3000 0.01 [sec.]
1388h Decel. overvolt. suppress propo-
tional gain
b133 R/W 0 to 500 0.01
1389h Decel. overvolt. suppress Inte-
gral time
b134 R/W 0 to 1500 0.1 [sec.]
138Ah to
1393h
(Reserved) – – – –
1394h GS input mode b145 R/W 0 (non Trip) /1 (Trip) –
1395h to
1399h
(Reserved) – – – –
139Ah Display ex.operator connected b150 R/W 001 to 060 -
139Bh to
13A2h
(Reserved) – – – –
13A3h 1st parameter of Dual Monitor b160 R/W 001 to 030 –
13A4h 2nd parameter of Dual Monitor b161 R/W 001 to 030 –
13A5h (Reserved) – – – –
13A6h Freq. set in monitoring b163 R/W 0 (disabling), 1 (enabling), –
13A7h Automatic return to the initial dis-
play
b164 R/W 0 (disabling), 1 (enabling), –
13A8h Ex. operator com. loss action b165 R/W 0 (tripping), 1 (tripping after decelerating
and stopping the motor), 2 (ignoring
errors), 3 (stopping the motor after free-
running), 4 (decelerating and stopping
the motor)
–
13A9h Data Read/Write select b166 R/W 0 (Read/Write OK), 1 (Protected) –
13AAh to
13ADh
(Reserved) – – – –
13AEh Inverter mode selection b171 R/W 0 (disabling), 1 (IM mode), 2 (High Freq.
mode), 3 (PM mode)
–
13AFh to
13B6h
(Reserved) – – – –
13B7h Initialization trigger b180 R/W 0 (disabling), 1 (enabling), –
13B8h to
1400h
unused – – Inaccessible –
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
To Next Page
