Omron MX2

307
ModBus Data Listing Section B-4
(vi) List of registers (2nd control settings)
(vii) List of registers (function modes for the 2nd control settings)
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
2103h Acceleration time (1),
2nd motor
F202 (high) R/W 1 to 360000 0.01 [sec.]
2104h F202 (low) R/W
2105h Deceleration time (1),
2nd motor
F203 (high) R/W 1 to 360000 0.01 [sec.]
2106h F203 (low) R/W
2107h to
2200h
unused – – Inaccessible –
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
2201h Frequency source, 2nd motor A201 R/W 0 (keypad potentiometer), 1 (control cir-
cuit terminal block), 2 (digital operator),
3 (Modbus), 4 (option ), 6 (pulse train
input), 7 (easy sequence), 10 (operation
function result)
–
2202h Frequency source, 2nd motor A202 R/W 1 (control circuit terminal block), 2 (digi-
tal operator), 3 (Modbus), 4 (option)
–
2203h Base frequency, 2nd motor A203 R/W 300 to "maximum frequency, 2nd motor" 0.1 [Hz]
2204h Maximum frequency,
2nd motor
A204 R/W 300 to 4000 0.1 [Hz]
2205h to
2215h
(Reserved) – – Inaccessible –
2216h Multispeed frequency setting,
2nd motor
A220 (high) R/W 0 or "start frequency" to "maximum
frequency, 2nd motor"
0.01 [Hz]
2217h A220 (low) R/W
2218h to
223Ah
(Reserved) – – Inaccessible –
223Bh Torque boost method selection,
2nd motor
A241 R/W 0 (manual torque boost), 1 (automatic
torque boost)
–
223Ch Manual torque boost value,
2nd motor
A242 R/W 20 to 200 1 [%]
223Dh Manual torque boost frequency,
2nd motor
A243 R/W 0 to 255 1 [%]
223Eh V/F characteristic curve selec-
tion, 2nd motor
A244 R/W 0 (VC), 1 (VP), 2 (free V/f),
3 (sensorless vector control)
-
223Fh V/f gain, 2nd motor A245 R/W 20 to 100 1 [%]
2240h Voltage compensation gain set-
ting for automatic torque boost,
2nd motor
A246 R/W 0 to 255 1
2241h Slippage compensation gain set-
ting for automatic torque boost,
2nd motor
A247 R/W 0 to 255 1
2242h to
224Eh
(Reserved) – – Inaccessible –
224Fh Frequency upper limit,
2nd motor
A261 (high) R/W 00 or "2nd minimum frequency limit" to
"maximum frequency, 2nd motor"
0.01 [Hz]
2250h A261 (low) R/W
2251h Frequency lower limit,
2nd motor
A262 (high) R/W 00 or "start frequency" to "maximum
frequency, 2nd motor limit"
0.01 [Hz]
2252h A262 (low) R/W
2253h to
2268h
(Reserved) – – Inaccessible –
2269h AVR function select, 2nd motor A281 R/W 0 (always on), 1 (always off), 2 (off
during deceleration)
–
226Ah AVR voltage select, 2nd motor A282 R/W 200 V class: 0 (200)/1 (215)/2 (220)/
3 (230)/4 (240)
400 V class: 5 (380)/6 (400)/7 (415)/
8 (440)/9 (460)/ 10 (480)
226Bh to
226Eh
(Reserved) – – Inaccessible –
