Omron MX2

308
ModBus Data Listing Section B-4
226Fh Acceleration time (2),
2nd motor
A292 (high) R/W 1 to 360000 0.01 [sec.]
2270h A292 (low) R/W
2271h Deceleration time (2),
2nd motor
A293 (high) R/W 1 to 360000 0.01 [sec.]
2272h A293 (low) R/W
2273h Select method to switch to Acc2/
Dec2, 2nd motor
A294 R/W 0 (switching by 2CH terminal), 1 (switch-
ing by setting), 2 (switching only when
the rotation is reversed)
–
2274h Acc1 to Acc2 frequency transi-
tion point, 2nd motor
A295 (high) R/W 0 to 40000 (100000) 0.01 [Hz]
2275h A295 (low) R/W
2276h Dec1 to Dec2 frequency transi-
tion point, 2nd motor
A296 (high) R/W 0 to 40000 (100000) 0.01 [Hz]
2277h A296 (low) R/W
2278h to
230Bh
(Reserved) – – – –
230Ch Level of electronic thermal,
2nd motor
b212 R/W 200 to 1000 0.1 [%]
230Dh Electronic thermal characteris-
tic, 2nd motor
b213 R/W 0 (reduced-torque characteristic), 1
(constant-torque characteristic), 2 (free
setting)
–
230Eh to
2315h
(Reserved) – – – –
2316h Overload restriction operation
mode, 2nd motor
b221 R/W 0 (disabling), 1 (enabling during acceler-
ation and constant-speed operation),
2 (enabling during constant-speed oper-
ation), 3 (enabling during acceleration
and constant-speed operation [speed
increase at regeneration])
–
2317h Overload restriction level, 2nd
motor
b222 R/W 100 to 2000 0.1[%]
2318h Deceleration rate at overload
restriction, 2nd motor
b223 R/W 1 to 30000 0.1[?]
2319h to
2428h
unused – – Inaccessible –
2429h Overload warning level 2,
2nd motor
C241 R/W 0 to 2000 0.1[%]
242Ah to
2501h
Unused – – Inaccessible –
2502h Motor data selection, 2nd motor H202 R/W 0 (standard motor data),
2 (auto-tuned data),
–
2503h Motor capacity, 2nd motor H203 R/W 00(0.1kW)- 15 (18.5kW) –
2504h Motor poles setting, 2nd motor H204 R/W 0 (2 poles), 1 (4 poles), 2 (6 poles),
3 (8 poles), 4 (10 poles)
–
2505h Motor speed constant, 2nd
motor
H205 R/W 1 to 1000 1[%]
2506h Motor stabilization constant, 2nd
motor
H206 R/W 0 to 255 1
2507h (Reserved) – – – –
2508h to
2515h
(Reserved) – – – –
2516h Motor constant R1, 2nd motor H220 (high) R/W 1 to 65535 0.001 [O]
2517h (Reserved) – – – –
2518h Motor constant R2, 2nd motor H221 (high) R/W 1 to 65535 0.001 [O]
2519h (Reserved) – – – –
251Ah Motor constant L, 2nd motor H222 (high) R/W 1 to 65535 0.01 [mH]
251Bh (Reserved) – – – –
251Ch Motor constant Io, 2nd motor H223 (high) R/W 1 to 65535 0.01 [A]
251Dh Motor constant J, 2nd motor H224 (high) R/W 1 to 9999000 0.001
251Eh H224 (low) R/W
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
