Monitoring Trip Events, History, & Conditions Section 6-2
Note Reset is not allowed in 10 second after trip.
Note When error E08, E14 and E30 occur, reset operation by RS terminal or STOP/
RESET key is not accepted. In this case, reset by cycling power. If still same
error occurs, perform initialization.
6-2-3 Parameter Warning Codes
If set parameter is conflicted to other parameters, warning code is displayed
as follows.
Error Code Name Descriptions
Rotat-
ing
Reset RS input is ON or STOP/RESET key is
pressed.
Undervoltage If input voltage is under the allowed level,
inverter shuts off output and wait with this indi-
cation.
Waiting to restart This indication is displayed after tripping before
restarting.
Restricted oper-
ation command
Commanded RUN direction is restricted in
b035.
Trip history
initializing
Trip history is being initialized.
No data
(Trip monitor)
No trip/waning data exists.
Blinking Communication
error
Communication between inverter and digital
operator fails.
Auto-tuning
completed
Auto-tuning is completed properly.
Auto-tuning error Auto-tuning fails.
Warning
code
Warning conditions
001
Frequency upper limit (A061) > Max. Frequency (A004)
002
Frequency lower limit (A062) > Max. Frequency (A004)
005
Output Frequency setting (F001)
Multi-speed freq. 0 (A020)
> Max. Frequency (A004)
015
Output Frequency setting (F001)
Multi-speed freq. 0 (A020)
> Frequency upper limit (A061)
025
Frequency lower limit (A062) > Output Frequency setting (F001)
Multi-speed freq. 0 (A020)
031
Start frequency (A082) > Frequency upper limit (A061)
032
Start frequency (A082) > Frequency lower limit (A062)
035
Start frequency (A082) > Output Frequency setting (F001)
Multi-speed freq. 0 (A020)
036
Start frequency (A082) > Multi-speed freq. 1-15
(A021-A035)
037
Start frequency (A082) > Jogging frequency (A038)
085
Output Frequency setting (F001)
Multi-speed freq. 0 (A020)
= Jump frequency
(A063/A063/A063±A064/
A066/A068)
086
Multi-speed freq. 1-15
(A021-A035)
