Omron MX2 - Three-Phase 400 V Class Specifications

6
MX2 Inverter Specifications Section 1-2
Item Three-phase 400V class Specifications
MX2 inverters, 400 V models A4004 A4007 A4015 A4022 A4030 A4040
Applica-
ble motor
size *2
kW VT 0.75 1.5 2.2 3.0 4.0 5.5
CT0.40.751.52.23.04.0
HPVT123457.5
CT1/212345
Rated
capacity
(kVA)
380 V VT 1.3 2.6 3.5 4.5 5.7 7.3
CT1.12.23.13.64.76.0
480 V VT 1.7 3.4 4.4 5.7 7.3 9.2
CT1.42.83.94.55.97.6
Rated input voltage Three-phase: 380 V-15% to 480 V+10%, 50/60 Hz±5%
Rated output voltage *3 Three-phase: 380 to 480 V (proportional to input voltage)
Rated output current
(A)
VT2.14.15.46.98.811.1
CT1.83.44.85.57.29.2
Starting torque *6 200% at 0.5 Hz
Braking Without resistor 100%: ≤50 Hz
50%: ≤60 Hz
70%: ≤50 Hz
50%: ≤60 Hz
With resistor 150%
DC braking Variable operating frequency, time, and braking force
Weight kg1.51.61.81.91.92.1
lb3.33.54.04.24.24.6
Item Three-phase 400V class Specifications
MX2 inverters, 200 V models A4055 A4075 A4110 A4150
Applica-
ble motor
size *2
kW VT 7.5 11 15 18.5
CT 5.5 7.5 11 15
HP VT 10 15 20 25
CT 7.5 10 15 20
Rated
capacity
(kVA)
380 V VT 11.5 15.1 20.4 25.0
CT 9.7 11.8 15.7 20.4
480 V VT 14.5 19.1 25.7 31.5
CT 12.3 14.9 19.9 25.7
Rated input voltage Three-phase: 380 V-15% to 480 V+10%, 50/60 Hz±5%
Rated output voltage *3 Three-phase: 380 to 480 V (proportional to input voltage)
Rated output current
(A)
VT 17.5 23.0 31.0 38.0
CT 14.8 18.0 24.0 31.0
Starting torque *6 200% at 0.5 Hz
Braking Without resistor 100%: ≤50 Hz
50%: ≤60 Hz
With resistor 150%
DC braking Variable operating frequency, time, and braking force
Weight kg 3.5 3.5 4.7 5.2
lb 7.7 7.7 10.4 11.5
