306
ModBus Data Listing Section B-4
Note 1 Above register (coil data 0 to 5) is consisted with 16 coil data. EzCOM com-
munication (inverter to inverter) doesn't support coil, but only register is sup-
porte, in case of need to access coil, please use above registers.
Note 2 Be sure not to write into above 1F02h to 1F1Dh.
16AEh Option I/F command register to
read 3
P172 R/W 0000 to FFFF –
16AFh Option I/F command register to
read 4
P173 R/W 0000 to FFFF –
16B0h Option I/F command register to
read 5
P174 R/W 0000 to FFFF –
16B1h Option I/F command register to
read 6
P175 R/W 0000 to FFFF –
16B2h Option I/F command register to
read 7
P176 R/W 0000 to FFFF –
16B3h Option I/F command register to
read 8
P177 R/W 0000 to FFFF –
16B4h Option I/F command register to
read 9
P178 R/W 0000 to FFFF –
16B5h Option I/F command register to
read 10
P179 R/W 0000 to FFFF –
16B6h Profibus Node address P180 R/W 0 to 125 –
16B7h Profibus Clear Node address P181 R/W 0(clear)/1(not clear) –
16B8h Profibus Map selection P182 R/W 0(PPO)/1(Comvertional) –
16B9h to
16BAh
(Reserved), – – – –
16BBh CANopen Node address P185 R/W 0 to 127
16BCh CAN open communication speed P186 R/W 0 (automatic) 5 (250kbps)
1 (10kbps) 6 (500kbps)
2 (20kbps) 7 (800kbps)
3 (50kbps) 8 (1Mbps)
4 (125kbps)
16BDh to
16BFh
Unused – – – –
16C0h CompoNet Node address P190 R/W 0 to 63 –
16C2h DeviceNet MAC ID P192 R/W 0 to 63 –
16C3h to
1E00h
Unused – – – –
1E01h Coil data 1 – R/W
2
1
: coil number 0010h -
2
15
: coil number 001Fh -
–
1E02h Coil data 2 – R/W
2
1
: coil number 0020h -
2
15
: coil number 002Fh -
–
1E03h Coil data 3 – R/W
2
1
: coil number 0030h -
2
15
: coil number 003Fh -
–
1E04h Coil data 4 – R/W
2
1
: coil number 0030h -
2
15
: coil number 003Fh -
–
1E05h Coil data 5 – R/W
2
1
: coil number 0040h -
2
15
: coil number 004Fh -
–
1E06h to
1F18h
(reserved) – - – –
1E19h to
1F00h
Unused – – – –
1F01h Coil data 0 – R/W
2
1
: coil number 0001h -
2
15
: coil number 000Fh -
–
1F02h to
1F1Dh
(reserved) – – (note: 2) –
1F1Eh to
2102h
Unused – – Inaccessible –
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
To Next Page
