Omron MX2 User Manual

323
Parameter Settings for Keypad Entry Section C-2
P041 Speed / torque control switching
time
0 ✓
P044 Network comm. Watchdog timer 1.00 ✕
P045 Inverter action on network comm
error
00 ✕
P046 Polled I/O output instance number 00 ✕
P048 Inverter action on network idle mode 01 ✕
P049 Network motor poles setting for
RPM
0.00 ✕
P055 Pulse train frequency scale 1.5 ✓
P056 Time constant of pulse
trainfrequency filter
0.10 ✓
P057 Pulse train frequency bias 0. ✓
P058 Pulse train frequency limit 100. ✓
P060 Multistage position 0 0. ✓
P061 Multistage position 1 0. ✓
P062 Multistage position 2 0. ✓
P063 Multistage position 3 0. ✓
P064 Multistage position 4 0. ✓
P065 Multistage position 5 0. ✓
P066 Multistage position 6 0. ✓
P067 Multistage position 7 0. ✓
P068 Homing mode selection 00 ✓
P069 Homing direction 01 ✓
P070 Low-speed homing frequency 5.00 ✓
P071 High-speed homing frequency 5.00 ✓
P072 Position range (forward) 268435455 ✓
P073 Position range (reverse) -268435455 ✓
P075 Positioning mode 00 ✕
P077 Encoder disconnection timeout 1.0 ✓
P100 EzSQ user parameter U (00) 0. ✓
P101 EzSQ user parameter U (01) 0. ✓
P102 EzSQ user parameter U (02) 0. ✓
P103 EzSQ user parameter U (03) 0. ✓
P104 EzSQ user parameter U (04) 0. ✓
P105 EzSQ user parameter U (05) 0. ✓
P106 EzSQ user parameter U (06) 0. ✓
P107 EzSQ user parameter U (07) 0. ✓
P108 EzSQ user parameter U (08) 0.
P109 EzSQ user parameter U (09) 0.
P110 EzSQ user parameter U (10) 0.
P111 EzSQ user parameter U (11) 0. ✓
P112 EzSQ user parameter U (12) 0. ✓
P113 EzSQ user parameter U (13) 0. ✓
P114 EzSQ user parameter U (14) 0. ✓
P115 EzSQ user parameter U (15) 0. ✓
P116 EzSQ user parameter U (16) 0. ✓
P117 EzSQ user parameter U (17) 0. ✓
P118 EzSQ user parameter U (18) 0. ✓
P119 EzSQ user parameter U (19) 0. ✓
"P" Group Parameters Default Setting B031=10 User
Setting
Func.
Code
Name (EU)

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
