290
ModBus Data Listing Section B-4
124Fh Frequency upper limit A061 (high) R/W 0 or "maximum frequency limit" to "max-
imum frequency"
0.01 [Hz]
1250h A061 (low) R/W
1251h Frequency lower limit A062 (high) R/W 0 or "maximum frequency limit" to "max-
imum frequency"
0.01 [Hz]
1252h A062 (low) R/W
1253h Jump freq. (center) 1 A063 (high) R/W 0 to 40000(100000) 0.01 [Hz]
1254h A063 (low) R/W
1255h Jump freq. width (hysteresis) 1 A064 R/W 0 to 1000(10000) 0.01 [Hz]
1256h Jump freq. (center) 2 A065 (high) R/W 0 to 40000(100000) 0.01 [Hz]
1257h A065 (low) R/W
1258h Jump freq. width (hysteresis) 2 A066 R/W 0 to 1000(10000) 0.01 [Hz]
1259h Jump freq. (center) 3 A067 (high) R/W 0 to 40000(100000) 0.01 [Hz]
125Ah A067 (low) R/W
125Bh Jump freq. width (hysteresis) 3 A068 R/W 0 to 1000(10000) 0.01 [Hz]
125Ch Acceleration hold frequency A069 (high) R/W 0 to 40000 0.01 [Hz]
125Dh A069 (low) R/W
125Eh Acceleration hold time A070 R/W 0 to 600 0.1 [sec.]
125Fh PID Function Enable A071 R/W 0 (disabling), 1 (enabling),
2 (enabling inverted-data output)
–
1260h PID proportional gain A072 R/W 0 to 2500 0.10
1261h PID integral time constant A073 R/W 0 to 36000 0.1 [sec.]
1262h PID derivative gain A074 R/W 0 to 10000 0.01 [sec.]
1263h PV scale conversion A075 R/W 1 to 9999 0.01
1264h PV source A076 R/W 0 (input via OI), 1 (input via O), 2 (exter-
nal communication), 3 (pulse train
frequency input), 10 (operation result
output)
–
1265h Reverse PID A077 R/W 00 (disabling), 01 (enabling) –
1266h PID output limiter A078 R/W 0 to 1000 0.1 [%]
1267h PID feed forward selection A079 R/W 0 (disabled), 1(O input), 2 (OI input) –
1268h (Reserved) – R/W – –
1269h AVR function select A081 R/W 0 (always on), 1 (always off), 2 (off dur-
ing deceleration)
–
126Ah AVR voltage select A082 R/W 200 V class: 0 (200)/1 (215)/2 (220)/3
(230)/4 (240
400 V class: 5 (380)/6 (400)/7 (415)/8
(440)/9 (460)/ 10 (480))
–
126Bh AVR filter time constant A083 R/W 0.000 to 10.00 0.001[sec]
126Ch AVR deceleration gain A084 R/W 50 to 200 1[%]
126Dh Energy-saving operation mode A085 R/W 0 (normal operation), 1 (energy-saving
operation)
–
126Eh Energy-saving mode tuning A086 R/W 0 to 1000 0.1 [%]
126Fh to
1273h
(Reserved) – – –
1274h Acceleration time (2) A092 (high) R/W 1 to 360000 0.01 [sec.]
1275h A092 (low) R/W
1276h Deceleration time (2) A093 (high) R/W 1 to 360000 0.01 [sec.]
1277h A093 (low) R/W
1278h Select method to switch to Acc2/
Dec2 profile
A094 R/W 0 (switching by 2CH terminal),
1 (switching by setting)
2 (Forward and reverse)
–
1279h Acc1 to Acc2 frequency transi-
tion point
A095 (high) R/W 0 to 40000(100000) 0.01 [Hz]
127Ah A095 (low) R/W
127Bh Dec1 to Dec2 frequency transi-
tion point
A096 (high) R/W 0 to 40000(100000) 0.01 [Hz]
127Ch A096 (low) R/W
127Dh Acceleration curve selection A097 R/W 0 (linear), 1 (S curve), 2 (U curve),
3 (inverted-U curve), 4 (EL-S curve)
–
127Eh Deceleration curve setting A098 R/W 0 (linear), 1 (S curve), 2 (U curve),
3 (inverted-U curve), 4 (EL-S curve)
–
127Fh (Reserved) – – – –
1280h (Reserved) – – – 0.01 [Hz]
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
