ModBus Data Listing Section B-4
1281h [OI] input active range start
frequency
A101 (high) R/W 0 to 40000(100000) 0.01 [Hz]
1282h A101 (low) R/W
1283h [OI] input active range end
frequency
A102 (high) R/W 0 to 40000(100000) 1 [%]
1284h A102 (low) R/W
1285h [OI] input active range start
current
A103 R/W 0 to "[OI]-[L] input active range end
current"
1 [%]
1286h [OI] input active range end
current
A104 R/W "[OI]-[L] input active range start current"
to 100
–
1287h [OI] input start frequency select A105 R/W 0 (external start frequency), 1 (0 Hz) –
1288h to
12A4h
(Reserved) – – – –
12A5h Acceleration curve constant A131 R/W 1 (smallest swelling) to 10
largest swelling)
–
12A6h Deceleration curve constant A132 R/W 1 (smallest swelling) to 10
(largest swelling)
-
12A7h to
12AEh
(Reserved) – – – –
12AFh Operation-target frequency
selection 1
A141 R/W 0 (digital operator), 1 (keypad potenti-
ometer), 2 (input via O), 3 (input via OI),
4 (external communication), 5 (option ),
7 (pulse train frequency input)
–
12B0h Operation-target frequency
selection 2
A142 R/W 0 (digital operator), 1 (keypad potenti-
ometer), 2 (input via O), 3 (input via OI),
4 (external communication), 5 (option ),
7 (pulse train frequency input)
–
12B1h Operator selection A143 R/W 0 (addition: A141 + A142), 1 (subtrac-
tion: A141 - A142), 2 (multiplication:
A141 x A142)
–
12B2h (Reserved) – – – –
12B3h Frequency to be added A145 (high) R/W 0 to 40000(100000) 0.01 [Hz]
12B4h A145 (low) R/W
12B5h Sign of the frequency to be
added
A146 R/W 00 (frequency command + A145),
01 (frequency command - A145)
–
12B6h to
12B8h
(Reserved) – – – –
12B9h EL-S-curve acceleration/deceler-
ation ratio 1
A150 R/W 0 to 50 1 [%]
12BAh EL-S-curve acceleration/deceler-
ation ratio 2
A151 R/W 0 to 50 1 [%]
12BBh EL-S-curve deceleration/decel-
eration ratio 1
A152 R/W 0 to 50 1 [%]
12BCh EL-S-curve deceleration/decel-
eration ratio 2
A153 R/W 0 to 50 1 [%]
12BDh Deceleration hold frequency A154 (high) R/W 0~40000(100000) 0.01 [Hz]
12BEh A154 (low)
12BFh Deceleration hold time A155 R/W 0~600 0.1 [sec.]
12C0h PID sleep function triggering
level
A156 (high) R/W 0~40000(100000) 0.01 [Hz]
12C1h A156 (low)
12C2h PID sleep function action delay
time
A157 R/W 0~255 0.1 [sec.]
12C3h to
12C5h
(Reserved) – – – –
12C6h [VR] input active range start
frequency
A161 (high) R/W 0~40000(100000) 0.01 [Hz]
12C7h A161 (low)
12C8h [VR] input active range end
frequency
A162 (high) R/W 0~40000(100000) 0.01 [Hz]
12C9h A162 (low)
12CAh [VR] input active range start % A163 R/W 0~
100 1 [%]
12CBh [VR] input active range end % A164 R/W 0~100 1 [%]
12CCh [VR] input start frequencyselect A165 R/W 0(start frequency A161) / 1(0Hz) –
12CDh
to 1300h
unused – – Inaccessible –
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
