292
ModBus Data Listing Section B-4
Parameter group B
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1301h Restart mode on power failure/
under-voltage trip
b001 R/W 0 (tripping), 1 (starting with 0 Hz), 2 (start-
ing with matching frequency), 3 (tripping
after deceleration and stopping with
matching frequency), 4 (restarting with
active matching frequency)
–
1302h Allowable under-voltage power
failure time
b002 R/W 3 to 250 0.1 [sec.]
1303h Retry wait time before motor restart b003 R/W 3 to 1000 0.1 [sec.]
1304h Instantaneous power failure/
under-voltage trip alarm enable
b004 R/W 0 (disabling), 1 (enabling), 2 (disabling
during stopping and decelerating to
stop)
–
1305h Number of restarts on power fail-
ure/under-voltage trip events
b005 R/W 0 (16 times), 1 (unlimited) –
1306h (Reserved) – – – –
1307h Restart frequency threshold b007 (high) R/W 0 to 40000 0.01 [Hz]
1308h b007 (low) R/W
1309h Restart mode on over voltage /
over current
b008 R/W 0 (tripping), 1 (starting with 0 Hz), 2 (start-
ing with matching frequency), 3 (tripping
after deceleration and stopping with
matching frequency), 4 (restarting with
active matching frequency)
–
130Ah (Reserved) – – – –
130Bh Number of retry on over voltage /
over current
b010 R/W 1 to 3 1 [time]
130Ch Retry wait time on over voltage /
over current
b011 R/W 3 to 1000 0.1 [sec.]
130Dh Level of electronic thermal b012 R/W 200 to 1000 0.1 [%]
130Eh Electronic thermal characteristic b013 R/W 0 (reduced-torque characteristic),
1 (constant-torque characteristic),
2 (free setting)
–
130Fh (Reserved) – – Inaccessible –
1310h Free setting, electronic thermal
frequency (1)
b015 R/W 0 to 400 1 [Hz]
1311h Free setting, electronic thermal
current (1)
b016 R/W 0 to Rated current 0.1 [A]
1312h Free setting, electronic thermal
frequency (2)
b017 R/W 0 to 400 1 [Hz]
1313h Free setting, electronic thermal
current (2)
b018 R/W 0 to Rated current 0.1 [A]
1314h Free setting, electronic thermal
frequency (3)
b019 R/W 0 to 400 1 [Hz]
1315h Free setting, electronic thermal
current (3)
b020 R/W 0 to Rated current 0.1 [A]
1316h Overload restriction operation
mode
b021 R/W 0 (disabling), 1 (enabling during acceler-
ation and constant-speed operation),
2 (enabling during constant-speed oper-
ation), 3 (enabling during acceleration
and constant-speed operation [speed
increase at regeneration])
–
1317h Overload restriction level b022 R/W 200 to 2000 0.1 [%]
1318h Deceleration rate at overload
restriction
b023 R/W 1 to 30000 0.1 [sec.]
1319h Overload restriction operation
mode (2)
b024 R/W 0 (disabling), 1 (enabling during acceler-
ation and constant-speed operation),
2 (enabling during constant-speed oper-
ation), 3 (enabling during acceleration
and constant-speed operation [speed
increase at regeneration])
–
131Ah Overload restriction level 2 b025 R/W 200 to 2000 0.1 [%]
131Bh Deceleration rate at overload
restriction (2)
b026 R/W 1 to 30000 0.1 [sec.]
131Ch Overcurrent suppression enable b027 R/W 0 (disabling), 1 (enabling) –
131Dh Current level of active freq. matching b028 R/W 100 to 2000 0.1 [%]
131Eh Deceleration rate of active freq.
matching
b029 R/W 1 to 30000 0.1 [sec.]
