293
ModBus Data Listing Section B-4
131Fh Start freq. of active frequency
matching
b030 R/W 0 (frequency at the last shutoff), 1 (max-
imum frequency), 2 (set frequency)
–
1320h Software lock mode selection b031 R/W 0 (disabling change of data other than
"b031" when SFT is on), 1 (disabling
change of data other than "b031" and fre-
quency settings when SFT is on), 2 (dis-
abling change of data other than "b031"),
3 (disabling change of data other than
"b031" and frequency settings), 10
(enabling data changes during operation)
–
1321h (Reserved) – – – –
1322h Motor cable length parameter b033 R/W 5 to 20 –
1323h Run/power-on warning time b034 (high) R/W 0 to 65535 1 [10h]
1324h b034 (low) R/W
1325h Rotation direction restriction b035 R/W 0( Enable for both dir)/ 1 (Enable for for-
ward only)/ 2 (Enable for reverse only)
–
1326h Reduced voltage start selection b036 R/W 0 (minimum reduced voltage start time)
to 255 (maximum reduced voltage start
time)
–
1327h Function code display restriction b037 R/W 0 (full display), 1 (function-specific dis-
play), 2 (user setting), 3 (data compari-
son display), 4 (basicdisplay), 5(monitor
display)
–
1328h Initial display selection b038 R/W 001-060 –
1329h Automatic user parameter regis-
tration
b039 R/W 0 (disabling), 1 (enabling) –
132Ah Torque limit selection b040 R/W 00 (quadrant-specific setting), 01
(switching by terminal), 02 (analog
input)
–
132Bh Torque limit 1 (fwd-power in
4-quadrant mode)
b041 R/W 0 to 200/255 (no) 1 [%]
132Ch Torque limit 2 (rev/regen. in
4-quadrant mode)
b042 R/W 0 to 200/255 (no) 1 [%]
132Dh Torque limit 3 (rev/power in
4-quadrant mode)
b043 R/W 0 to 200/255 (no) 1 [%]
132Eh Torque limit 4 (fwd/regen. in
4-quadrant mode)
b044 R/W 0 to 200/255 (no) 1 [%]
132Fh Torque limit LADSTOP enable b045 R/W 0 (disabling), 1 (enabling) –
1330h Reverse Run protection enable b046 R/W 0 (disabling), 1 (enabling) –
1331h to
1332h
(Reserved) – – – –
1333h Dual Rating Selection b049 R/W 0(CT mode)/1(VT mode) –
1334h Controlled deceleration on
power loss
b050 R/W 0 (disabling), 1 (enabling), 2, (nonstop
operation at momentary power failure
(no restoration)) 3, (nonstop operation
at momentary power failure (restoration
to be done))
–
1335h DC bus voltage trigger level of
ctrl. decel.
b051 R/W 0 to 10000 0.1 [V]
1336h Over-voltage threshold of ctrl.
decel.
b052 R/W 0 to 10000 0.1 [V]
1337h Deceleration time of ctrl. decel. b053 (high) R/W 0.01 to 36000 0.01 [sec.]
1338h b053 (low) R/W
1339h Initial freq. drop of ctrl. decel. b054 R/W 0 to 1000 0.01 [Hz]
133Ah to
133Eh
(Reserved) v – – –
133Fh Maximum-limit level of window
comparators O
b060 R/W 0. to 100. (lower limit : b061 + b062 *2)
(%)
1 [%]
1340h Minimum-limit level of window
comparators O
b061 R/W 0. to 100. (lower limit : b060 - b062*2) (%) 1 [%]
1341h Hysteresis width of window
comparators O
b062 R/W 0. to 10. (lower limit : b061 - b062 / 2) (%) 1 [%]
1342h Maximum-limit level of window
comparators OI
b063 R/W 0. to 100. (lower limit : b064 + b066 *2)
(%)
1 [%]
1343h Minimum-limit level of window
comparators OI
b064 R/W 0. to 100. (lower limit : b063 - b066 *2) (%) 1 [%]
1344h Hysteresis width of window
comparators OI
b065 R/W 0. to 10. (lower limit : b063 - b064 / 2) (%) 1 [%]
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
