24
Orientation to Inverter Features Section 2-1
3-phase 200 V 3.7 kW
3-phase 400V 4.0 kW
3-phase 200 V 5.5, 7.5 kW
3-phase 400 V 5.5, 7.5 kW
(1) Cooling fan cover (5) Terminal block cover
(2) Cooling fan (6) Optional board cover
(3) Cooling fin (7) Backing plate
(4) Main housing
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
