63
Using the Keypad Devices Section 3-2
When ND is selected, following functions are not displayed in intelligent termi-
nals.
b046 Reverse run protection H024/H224 Motor constant J
C054 Over-torque/under-torque selection P037 Torque bias value
C055 Over/under-torque level (FW,PW) P038 Torque bias polar selection
C056 Over/under-torque level (RV,RG) P039 Speed limit of Torque control (FW)
C057 Over/under-torque level (RV,PW) P040 Speed limit of Torque control (RV)
Func. code Name Func. code Name
Intelligent input terminals Intelligent output terminals
40:TL Torque Limit Selection 07:OTQ Over/under Torque Signal
41:TRQ1 Torque limit switch 1 10:TRQ Torque Limited Signal
42:TRQ1 Torque limit switch 2 - -
52:ATR Enable torque command input - -
