40 Specifications
481
1. Refer to “Monitor Performance Specifications” on page 464 for system alarm delay specification.
Pulse Oximeter
Calibration Range
70% to 100%
SpO
2
Performance Specifications
SpO
2
Alarm Specifications Range Adjustment
SpO
2
high and low limit alarms Adult: 50 to 100%
Pedi/Neo: 30 to 100%
1% steps
Desat Adult: 50% to Low alarm limit
Pedi/Neo: 30% to Low alarm limit
1% steps
Pulse 30 to 300 bpm Adult:
1 bpm steps (30 to 40 bpm)
5 bpm steps (40 to 300 bpm)
Pedi/Neo:
1 bpm steps (30 to 50 bpm)
5 bpm steps (50 to 300 bpm)
Tachycardia Difference to high limit 0 to 50 bpm 5 bpm steps
Clamping at 150 to 300 bpm 5 bpm steps
Bradycardia Difference to low limit 0 to 50 bpm 5 bpm steps
Clamping at 30 to 100 bpm 5 bpm steps
SpO
2
Alarm
Specifications (cont.)
Standard Delay
Smart Alarm Delay (alternative to standard alarm delay)
Short Mode Medium mode Long Mode
SpO
2
high and low limit
alarms
0 to 30 seconds (adjustable in
1 second steps) + system alarm
delay
1
10 to 25 seconds +
system alarm delay
10 to 50 seconds
+system alarm delay
10 to 100 seconds +
system alarm delay
Desat 0 to 30 seconds (adjustable in
1 second steps) + system alarm
delay
not supported
Pulse 10 seconds + system alarm delay
Tachycardia 10 seconds + system alarm delay
Bradycardia 10 seconds + system alarm delay
SpO
2
Smart Alarm Delay - Detailed Specifications
Deviation from violated
alarm limit
Resulting alarm delay according to selected mode
Short Medium Long
1% 25 sec
(maximum delay)
50 sec
(maximum delay)
100 sec
(maximum delay)
2% 12 sec 25 sec 50 sec
3% 10 sec 16 sec 33 sec
4% 10 sec 12 sec 25 sec
5% 10 sec 10 sec 20 sec
6% 10 sec 10 sec 16 sec
7% 10 sec 10 sec 14 sec
8% 10 sec 10 sec 12 sec
