AUTOMATIC NUMBER IDENTIFICATION (ANI)
PROGRAMMING
(1) DTI Assignment for ANI
DESCRIPTION DATA
Assign a trunk route number to each DTI. •
(1)
(2)
Y=00
000-255: Trunk No.
00-63: Trunk Route No.
Specify the Terminating System in Day Mode,
Night Mode, Mode A and Mode B for incom-
ing calls.
•
•
•
•
(1)
(2)
Y=02 Day Mode
Y=03 Night Mode
Y=40 Mode A
Y=41 Mode B
000-255: Trunk No.
31 : DID, Tie line and any call which is
not handled by the PBX
Assign the trunk route data to each DTI route. •
(1)
(2)
Y=00 Kind of trunk route
00-63: Trunk Route No.
00: DDD (C.O./DID), ISDN trunk
•
(1)
(2)
Y=04 Answer signal from distant office
00-63: Trunk Route No.
2: Answer signal arrives
•
(1)
(2)
Y=05 Release signal from distant office
00-63: Trunk Route No.
1 : Release signal arrives
•
(1)
(2)
Y=09 Incoming connection signaling
00-63: Trunk Route No.
03: Wink Start
•
(1)
(2)
Y=10 2nd DT sending on call termination
00-63: Trunk Route No.
0: 2nd Dial Tone is not sent
START
CM30
CM35
A
AUTOMATIC NUMBER IDENTIFICATION (ANI)
To Next Page
