ADD-ON MODULE
PROGRAMMING
DESCRIPTION DATA
Assign the Add-On Module number to its asso-
ciated LEN.
NOTE: When the data assignment of both
DSS Console and Add-On Module
are required, the same number (the
last two digits of the data) cannot be
used.
(1)
(2)
000-763: LEN
EC00-EC31: Add-On Module No.
For PIM0/1 : EC00-EC07
For PIM2/3 : EC08-EC15
For PIM4/5 : EC16-EC23
For PIM6/7 : EC24-EC31 NOTE
Assign the Add-On Module number to its asso-
ciated LEN.
[Series 3200 R6.2 software required]
NOTE: When the data assignment of both
DSS Console and Add-On Module
are required, the same number (the
last two digits of the data) cannot be
used.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
EC00-EC31 : Add-On Module No.
For FP No. 00: EC00-EC07
For FP No. 01: EC08-EC15
For FP No. 02: EC16-EC23
For FP No. 03: EC24-EC31 NOTE
Assign the D
term
which is associated with the
Add-On Module.
NOTE: The D
term
and the Add-On Module
must be in the same PIM.
•
(1)
(2)
Y=0
00-31: Last two digits of Add-On
Module No.
EC00-EC31
X-XXXXXXXX: My Line No.
Assign the Service Restriction Class for the
accommodation of Single-Line Telephone to
D
term
. (Assignment for Single-Line Telephone
only).
•
(1)
(2)
Y=05
X-XXXXXXXX: Station No.
0: Accommodated
Assign the station and trunk numbers to the
keys on each Add-On Module.
NOTE: Single-Line, Virtual Line or My Line
can be assigned on Add-On Module.
•
(1)
(2)
Y=00
My Line No. + + Add-On Module Key
No. (30-54)
X-XXXXXXXX: Station No. NOTE
DXXX
XXX: 000-255 (Trunk No.)
START
CM10
CM14
CM98
CM90
,
A
ADD-ON MODULE
