– 698 – NWA-008845-001 Rev.5.0
32ch1011.fm
TIMED FORCED RELEASE
[Series 3500 software required]
PROGRAMMING
DESCRIPTION DATA
Provide the outgoing trunk route with forced
release in designated time.
•
(1)
(2)
Y=247
00-63: Trunk Route No.
0: To provide
1: Not provided
Provide the incoming trunk route with forced
release in designated time.
•
(1)
(2)
Y=248
00-63: Trunk Route No.
0: To provide
1: Not provided
Specify the warning SST sending timer for
forced release, Timer A, B and C respectively.
NOTE: Set the time from the start of commu-
nications to the warning SST is sent.
Forced release is executed at 16 sec-
onds later from the warning SST is
sent.
•
(1)
(2)
Y=0
114: Timer A
115: Timer B
116: Timer C
01-99: 64-6336 seconds
(64 second increments)
NONE : No data
Specify the warning SST sending timer for
forced release to the required stations.
NOTE: This data is effective when the
forced release is provided to the des-
tination trunk route (CM35 Y=247
and CM35 Y=248 is set to 0).
•
(1)
(2)
Y=61
X-XXXXXXXX: Station No.
0 : Depends on Timer A
1 : Depends on Timer B
2 : Depends on Timer C
3 : Forced Release is not provided
START
CM35
CM41
CM12
A
TIMED FORCED RELEASE
To Next Page
