DIAL CONVERSION
PROGRAMMING
DESCRIPTION DATA
Assign the card number of the DTMF Receiver
to the required LEN.
NOTE: E200 is dedicated to built-in DTMF
Receiver of the MP card.
(1)
(2)
000-763: LEN
Card No. of DTMF Receiver (8RST)
For PIM0/1 : E201-E203
For PIM2/3 : E204-E207
For PIM4/5 : E208-E211
For PIM6/7 : E212-E215
Assign the card number of the DTMF Receiver
to the required LEN.
[Series 3200 R6.2 software required]
NOTE: E200 is dedicated to built-in DTMF
Receiver of the MP card.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
Card No. of DTMF Receiver (8RST)
For FP No. 00 : E201-E203
For FP No. 01 : E204-E207
For FP No. 02 : E208-E211
For FP No. 03 : E212-E215
Assign the type of telephone set to DTMF
stations. This data assignment is not required
for D
term
stations.
•
(1)
(2)
Y=00
X-XXXXXXXX: Station No.
2: DTMF Telephone set
Assign DTMF Receivers for use with DTMF
stations.
•
(1)
(2)
Y=0 Make Busy
XX Z
XX: DTMF Receiver Card No.
00: MP Built-in DTMF Receiver
01-15: PN-8RST
Z : 0-3: Circuit No.
1 : In service
•
(1)
(2)
Y=1 PBR for incoming call from Tie Line/
DID
XX Z: Same as CM45 Y=0
1 : For both DTMF station and Tie Line/
DID
START
CM10
CM14
CM12
CM45
A
DIAL CONVERSION
