DIAL INTERCOM
PROGRAMMING
DESCRIPTION DATA
Assign a Dial Intercom number to the Virtual
LEN. The last two digits of each Dial Intercom
number represent the Dial Intercom Group
number.
The first digit is the intercom code (0-9) as-
signed to the associated virtual extension.
NOTE: A maximum of 25 Dial Intercom
groups are available per system. A
maximum of ten D
term
s can belong
to a Dial Intercom group.
(1)
(2)
000-255: Virtual LEN
[Series 3300 software or before]
0000-1019: Virtual LEN
[Series 3400 software or later]
B000-B024
B100-B124
B200-B224
B300-B324
B400-B424
B500-B524
B600-B624
B700-B724
B800-B824
B900-B924
(Dial Intercom Number)
B X YY
X : 0-9: Intercom Code
YY: 00-24: Dial Intercom Group No.
Assign the Dial Intercom station. •
(1)
(2)
Y=03
B000-B924: Dial Intercom No. assigned by
CM11
07: Dial Intercom
Assign the My Line number to each Dial Inter-
com number.
•
(1)
(2)
Y=12
B000-B924: Dial Intercom No.
X-XXXXXXXX: My Line No.
Assign the DIAL INTERCOM key to each
D
term
.
•
(1)
(2)
Y=00
My Line No. + + key No.
Dial Intercom No. of each D
term
START
CM11
GROUP No. INTERCOM No.
00
01
24
B000, B100, B200 — B900
B001, B101, B201 — B901
B024, B124, B224 — B924
~ ~
CM12
CM56
CM90
,
A
INTERCOM
DIAL INTERCOM
