MY LINE NUMBER DISPLAY
[Series 3400 software required]
PROGRAMMING
HARDWARE REQUIRED
D
term
and DLC card
DESCRIPTION DATA
Assign Service Restriction Class A to each sta-
tion.
•
(1)
(2)
Y=02
X-XXXXXXXX: Station No.
XX ZZ
XX: 00-15 : Service Restriction Class A
Allow the My Line number display in the Ser-
vice Restriction Class A assigned by CM12
Y=02.
•
(1)
(2)
Y=210
00-15: Service Restriction Class A
0: Available
Specify whether Calling number will be dis-
played when a calling station abandons a call
before the call is answered.
(1)
(2)
311
0 : Not available
1 : Available
After the above data setting is completed,
allow the system to request the My Line num-
ber information of D
term
station by CM12
Y=29.
The My Line number information is sent to a
D
term
control section of the system according
to CM15 Y=210 data setting.
When sending the My Line number informa-
tion is completed, 2nd data of CM15 Y=210
returns to 1 from 0.
•
(1)
(2)
Y=29
X-XXXXXXXX: Station No.
0 : Allow
1 : Not allowed
NOTE 1: When you change CM15 Y=210 data under On-line mode (without CM12 Y=29 data set-
ting), you need to wait several hours until the My Line number display is activated.
NOTE 2: To activate the My Line number display immediately after setting CM15 Y=210 under On-
line mode, set 2nd data of CM12 Y=29 to 1(Request a D
term
station to send the My Line
number).
NOTE 3: The My Line number display is activated immediately after plugging or unplugging D
term
cable or resetting the system.
START
CM12
CM15
CM08
CM12
END
JULY/01/2006
PROPRIETARY MULTILINE TERMINAL
MY LINE NUMBER DISPLAY
