Philips Sopho 2000 IPS - Code Calling Equipment Access

– 481 – NWA-008845-001 Rev.5.0
32ch1008.fm
CODE CALLING EQUIPMENT ACCESS
PROGRAMMING
DESCRIPTION DATA
Assign the interface trunk (COT card and DK
card) to the required LEN.
NOTE 1: The DK card number must be as-
signed to the first LEN (Level 0) and
the third LEN (Level 2) of each LT
Slot.
(1)
(2)
000-763: LEN
D000-D255: COT card
E800-E831 : DK card
For PIM0/1: E800-E807
For PIM2/3: E808-E815
For PIM4/5: E816-E823
For PIM6/7: E824-E831
NOTE 2: Circuit No. 3 of E831 is used for
built-in External Equipment In-
terface of MP card by setting
CM44.
Assign the interface trunk (COT card and DK
card) to the required LEN.
[Series 3200 R6.2 software required]
NOTE 1: The DK card number must be as-
signed to the first LEN (Level 0) and
the third LEN (Level 2) of each LT
Slot.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
D000-D255: COT card
E800-E831 : DK card
For FP No. 00: E800-E807
For FP No. 01: E808-E815
For FP No. 02: E816-E823
For FP No. 03: E824-E831
NOTE 2: Circuit No. 3 of E831 is used for
built-in External Equipment In-
terface of MP card by setting
CM44.
Specify ON/OFF condition for external relay/
external key on MP built-in DK00 card.
(1)
(2)
700
0 : ON (Ground Start)
OFF (Ground Off [Open])
1 : ON (Ground Off [Open])
OFF (Ground Start)
START
CM10
CM14
CM08
A
JULY/01/2006
MISCELLANEOUS TRUNK ACCESS
CODE CALLING EQUIPMENT ACCESS
