Philips Sopho 2000 IPS - Trunk Group Busy Display

– 77 – NWA-008845-001 Rev.5.0
32ch1001.fm
TRUNK GROUP BUSY DISPLAY
PROGRAMMING
HARDWARE REQUIRED
To provide the Trunk Group Busy Lamps externally:
DK card and lamp indicator provided by customer
DESCRIPTION DATA
Assign the trunk group number to each trunk.
Several trunks may be assigned to one trunk
group number.
•
(1)
(2)
Y=09
000-255: Trunk No.
01-62: Trunk Group No.
For providing the Trunk Group Busy Lamps
on Attendant Console, assign the trunk group
number to required key.
NOTE 1: Maximum 6 keys per DESKCON
can be assigned. Any six trunk group
number out of trunk group number
01-62 can be assigned.
NOTE 2: Key number 1-6 should not be
assigned to provide a Trunk Group
Busy Lamp.
•
(1)
(2)
Y=00
ATTCON No. (E000-E007) + + Key
No.
F12XX
XX: 01-62: Trunk Group No. assigned by
CM30 Y=09
For providing external Trunk Group Busy
Lamps, assign the trunk group number to the
required circuit number on the DK card or
circuit number of the external relay control on
the MP card.
(1)
(2)
XX Y
XX: 00-31: DK Card No. E800-E831
assigned by CM10/CM14
Y : 0-3: Circuit No.
313: Built-in DK on MP card
11XX
XX: 01-62: Trunk Group No. assigned by
CM30 Y=09
START
CM30
CM90
,
CM44
END
ATTENDANT CONSOLE
TRUNK GROUP BUSY DISPLAY
