DICTATION EQUIPMENT ACCESS
PROGRAMMING
NOTE: For assigning the Class of Service for this feature, refer to CLASS OF SERVICE.
Page 211
DESCRIPTION DATA
Assign the trunk number to the required LEN. (1)
(2)
000-763: LEN
D000-D255: Trunk No.
Assign the trunk number to the required LEN.
[Series 3200 R6.2 software required]
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
D000-D255: Trunk No.
Assign the trunk data to the trunk number. •
(1)
(2)
Y=00 Trunk route allocation
000-255: Trunk No.
00-63: Trunk Route No.
Dedicated route number for this service
should be assigned.
•
(1)
(2)
Y=01 Tenant allocation
000-255: Trunk No.
00-63: Tenant No.
Assign the route data to the trunk route speci-
fied by CM30 Y=00.
•
(1)
(2)
Y=00 Kind of Route
00-63: Trunk Route No.
05
•
(1)
(2)
Y=01 Type of Signal to be sent out
00-63: Trunk Route No.
4: DTMF
•
(1)
(2)
Y=08 Dial Pulse Sending
00-63: Trunk Route No.
3: To send
Assign the access code for this service. •
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code
100-163: Trunk Route No. 00-63 assigned
by CM30 Y=00
START
CM10
CM14
CM30
CM35
CM20
END
MISCELLANEOUS TRUNK ACCESS
DICTATION EQUIPMENT ACCESS
