– 440 – NWA-008845-001 Rev.5.0
32ch1007.fm
LINE LOCKOUT
PROGRAMMING
DESCRIPTION DATA
Provide the system with Howler Tone sent to
locked-out stations, if required.
(1)
(2)
153
0: Not sent
1: To send
Assign the line lockout indication on the DSS
Console.
(1)
(2)
274
0 : Available
1 : Not available
When the Howler Tone is provided
(CM08>153=1), assign Howler Tone sending
to required stations.
•
(1)
(2)
Y=04
X-XXXXXXXX: Station No.
1: To provide
Specify the timing for Lockout Alarm. •
(1)
(2)
Y=0
22
01-08: 4-32 seconds
(4 second increments)
If no data is set, the default setting is 28-32 sec-
onds.
Specify the number of stations in Line Lockout
to give a MN Alarm.
(1)
(2)
01
01-99 : 1 station-99 stations
NONE : No “Lockout Alarm Display”
START
CM08
CM13
CM41
CM42
END
LINE LOCKOUT
To Next Page
