– 818 – NWA-008845-001 Rev.5.0
32ch2001.fm
MESSAGE WAITING
PROGRAMMING
To provide the Message Waiting from an administrative station, Front Desk Terminal, or PMS:
NOTE: PMS with AP00 on RS-232C is not available when using PN-AP00-B/PN-AP00-D with MRCA
program.
DESCRIPTION DATA
Assign Service Restriction Class A for Mes-
sage Waiting to required guest or administra-
tive station as shown below.
•
(1)
(2)
Y=02
X-XXXXXX: Station No.
XX ZZ
XX: 00-15 : Service Restriction Class A
Allow Message Waiting in Service Restriction
Class A assigned by CM12 Y=02.
•
•
(1)
(2)
Y=24 Administrative station allowing
Message Waiting set/reset to guest room
Y=40 Guest Station
00-15: Service Restriction Class A as-
signed by CM12 Y=02
0 : Restricted
1 : Allow
Provide each station with Message Waiting
Service (D
term
or Single Line Telephone with
Message Waiting Lamp).
•
(1)
(2)
Y=03
X-XXXXXX: Station No.
0: To provide
Specify guest station or administrative
station to each station.
NOTE 1: This data assignment is not required
when Message Waiting is set by
PMS.
•
(1)
(2)
Y=13
X-XXXXXX: Station No.
0 : Administrative station
1 : Guest station
START
CM12
CM15
Administrative station
GUEST/ADMINISTRATIVE
0
Guest station w/o MW
CM15
Y=40
CM15
Y=24
Lamp
Guest station with MW
Lamp
0
01
10
CM13
A
JUNE/01/2007
HOTEL SYSTEM PROGRAMMING
MESSAGE WAITING
To Next Page
