Frame Configuration of 24DTI
According to the AT&T Specifications for 24-channel transmission, there are two types of frame config-
urations: 12-Multi Frame (D4) and 24-Multi Frame (ESF).
1. 12-Multi Frame
This configuration has 12-Multi Frames, and each Multi frame has a 24-channel PCM signal (8 bits/
channel) and a S bit (Super Frame Bit). Figure below shows the frame configuration, and Table in
next page shows frame bit assignment.
DTI Frame Configuration (12-Multi Frame)
S
CH1 CH2 CH3 CH24
123456781234567812345678 12345678
FRAME 1 FRAME 2 FRAME 3 FRAME 12
125 µs
S: SUPERFRAME BIT
JULY/01/2006
DIRECT DIGITAL INTERFACE
DTI SPECIFICATIONS
