– 584 – NWA-008845-001 Rev.5.0
32ch1009.fm
RELAY CONTROL FUNCTION KEY
PROGRAMMING
DESCRIPTION DATA
Assign the DK card to the required LEN.
NOTE 1: The DK card number must be as-
signed to the first LEN (Level 0) and
the third LEN (Level 2) of each LT
slot.
NOTE 2: Circuit No. 3 of E831 is used for
built-in External Equipment Inter-
face of MP card by setting CM44.
(1)
(2)
000-763: LEN
E800-E831 : DK Card No.
For PIM0/1: E800-E807
For PIM2/3: E808-E815
For PIM4/5: E816-E823
For PIM6/7: E824-E831
Assign the DK card to the required LEN.
[Series 3200 R6.2 software required]
NOTE 1: The DK card number must be as-
signed to the first LEN (Level 0) and
the third LEN (Level 2) of each LT
slot.
NOTE 2: Circuit No. 3 of E831 is used for
built-in External Equipment Inter-
face of MP card by setting CM44.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
E800-E831 : DK Card No.
For FP No. 00: E800-E807
For FP No. 01: E808-E815
For FP No. 02: E816-E823
For FP No. 03: E824-E831
Specify ON/OFF condition for external relay/
external key on MP built-in DK00 card.
(1)
(2)
700
0 : ON (Ground Start)
OFF (Ground Off [Open])
1 : ON (Ground Off [Open])
OFF (Ground Start)
Assign the function of relay control via D
term
to the DK.
(1)
(2)
XX Y
XX: 00-31: DK Card No. E800-E831
assigned by CM10/CM14
Y : 0-3: Circuit No.
313: MP Built-in External Equipment In-
terface
1500: Relay Control (On/Off) Function
Key via D
term
Assign the Relay Control (ON/OFF) key on
the required D
term
.
•
(1)
(2)
Y=00
My Line No. + + Key No.
F7 XX Z
XX: 00-31: DK Card No. assigned by
CM44
Z : 0-3: Circuit No. assigned by CM44
START
CM10
CM14
CM08
CM44
CM90
,
END
JULY/01/2006
PROPRIETARY MULTILINE TERMINAL
RELAY CONTROL FUNCTION KEY
To Next Page
