RING FREQUENCY CONTROL
PROGRAMMING
To control the ring frequency by system data programming:
DESCRIPTION DATA
Enable the frequency control by system data
programming.
(1)
(2)
390
1 : As per CM15 Y=83, 84, 93, CM35
Y=34, 164, CM65 Y=40
Assign Service Restriction Class C to each sta-
tion.
•
(1)
(2)
Y=07
X-XXXXXXXX: Station No.
00-15 : Service Restriction Class C
Specify the Ringer Tone Pattern of the D
term
for terminating calls from a station in the Ser-
vice Restriction Class C assigned by CM12
Y=07.
•
(1)
(2)
Y=83, 84, 93
00-15: Service Restriction Class C
assigned by CM12 Y=07
See the table below.
[Series 3200 R6.1 software required]
Specify the Ringer Tone Pattern of the D
term
to
each trunk route.
•
(1)
(2)
Y=34, 164
00-63: Trunk Route No.
See the table below.
[Series 3200 R6.1 software required]
START
CM08
INITIAL
CM12
CM15
Y=83 Y=84 Y=93: 0 Y=93: 1
0 0 Ringer Tone Pattern 3 Ringer Tone Pattern 7
0 1 Ringer Tone Pattern 6 Ringer Tone Pattern 1
1 0 Ringer Tone Pattern 5 Ringer Tone Pattern 0
1 1 Ringer Tone Pattern 4 Ringer Tone Pattern 2
CM35
Y=34 Y=164: 0 Y=164: 1
0 Ringer Tone Pattern 3 Ringer Tone Pattern 0
1 Ringer Tone Pattern 6 Ringer Tone Pattern 1
2 Ringer Tone Pattern 5 Ringer Tone Pattern 2
3 Ringer Tone Pattern 4 Ringer Tone Pattern 7
A
PROPRIETARY MULTILINE TERMINAL
RING FREQUENCY CONTROL
