PAD LOCK
PROGRAMMING
(1) To change the Station Class with Station Authorization Code
DESCRIPTION DATA
Assign Service Restriction Class A to each sta-
tion.
•
(1)
(2)
Y=02
X-XXXXXXXX: Station No.
XX ZZ
XX: 00-15 : Service Restriction Class A
Allow Authorization Code in Service Restric-
tion Class A assigned by CM12 Y=02.
•
(1)
(2)
Y=31 Authorization Code
00-15: Service Restriction Class A as-
signed by CM12 Y=02
1 : Allow
Allow Authorization Code operation after op-
erating trunk call originating in Service Re-
striction Class A assigned by CM12 Y=02.
[Series 3900 software required]
•
(1)
(2)
Y=401
00-15: Service Restriction Class A as-
signed by CM12 Y=02
2 : Allow
7 : Restricted
Specify the number of digits for Station Autho-
rization Code.
(1)
(2)
73
01-08 : 1 digit-8 digits
NONE : 4 digits
Assign the access code for Station Class
change with Station Authorization Code.
•
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code
A230: Station Class change with Station
Authorization Code
Assign the temporary Trunk Restriction Class
to be applied to each station after the station
class is changed.
•
(1)
(2)
Y=01
X-XXXXXXXX: Station No.
1-8: Trunk Restriction Class
1 : Unrestricted (RCA)
2 : Non-Restricted 1 (RCB)
3 : Non-Restricted 2 (RCC)
4 : Semi-Restricted 1 (RCD)
5 : Semi-Restricted 2 (RCE)
6 : Restricted 1 (RCF)
7 : Restricted 2 (RCG)
8 : Fully-Restricted (RCH)
START
CM12
CM15
CM42
CM20
CM2B
A
