TENANT SERVICE
PROGRAMMING
DESCRIPTION DATA
Assign a Tenant number to each station. •
(1)
(2)
Y=04
X-XXXXXXXX: Station No.
00 : Tenant No. 00
01 -63: Tenant No. 01-63
Assign a Tenant number to each trunk. •
(1)
(2)
Y=01
000-255: Trunk No.
00 : Tenant No. 00
01 -63: Tenant No. 01-63
Assign a Numbering Plan Group number to
each Tenant.
(1)
(2)
00-63: Tenant No.
710-713: Numbering Plan Group 0-3
Assign required access codes for each Num-
bering Plan Group.
To provide a trunk route for each Tenant, as-
sign Tenant Block 00-23 to desired Trunk
Route access code.
•
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code
A000-A097
801-818
A100-A152
100-163
300-323: Tenant Block 00-23
When Tenant Block 00-23 is assigned by
CM20, assign a trunk route and Tenant number
to the Tenant Block.
•
(1)
(2)
Y=00-23 Tenant Block 00-23
00-63: Tenant No.
100-163: Trunk Route 00-63
When an External Key for Day/Night Mode
change or Class of Service change is required,
assign the DK card to required LEN.
NOTE 1: The DK card number must be as-
signed to the first LEN (level 0) and
the third LEN (Level 2).
(1)
(2)
000-763: LEN
E900-E963 : DK Card No.
For PIM0/1: E900-E915
For PIM2/3: E916-E931
For PIM4/5: E932-E947
For PIM6/7: E948-E963
NOTE 2: Circuit No. 3 of E963 is used for
built-in External Key Interface of
MP card by setting CM61.
START
CM12
CM30
CM29
CM20
CM23
CM10
A
