Philips Sopho 2000 IPS - Tie Lines

– 688 – NWA-008845-001 Rev.5.0
32ch1011.fm
TIE LINES
PROGRAMMING
DESCRIPTION DATA
Assign a trunk number for the ODT card to the
required LEN.
NOTE: The trunk number must be assigned
to the first LEN (Level 0) and the
second LEN (Level 1) of each LT
slot.
(1)
(2)
000-763: LEN
D000-D255: Trunk No.
Assign a trunk number for the ODT card to the
required LEN.
[Series 3200 R6.2 software required]
NOTE: The trunk number must be assigned
to the first LEN (Level 0) and the
second LEN (Level 1) of each LT
slot.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
D000-D255: Trunk No.
Assign a trunk route access code to each Tie
Line trunk route.
•
(1)
(2)
Y=0-3 Numbering Plan Group 0-3
X-XXXX: Access Code (81/82)
100-163: Trunk Route 00-63 (01/02)
Assign a trunk route and tenant number to each
trunk.
•
(1)
(2)
Y=00
000-255: Trunk No.
00-63: Trunk Route No. (01/02)
•
(1)
(2)
Y=01
000-255: Trunk No.
00-63: Tenant No. (00/00)
Assign trunk route data to the trunk route num-
ber assigned by CM30 Y=00.
NOTE 1: All circuits in one ODT card must be
set to same type interface (2-wire or
4-wire).
NOTE 2: For Type II signaling by 4ODT
card, set JP1-4 switch to DOWN.
•
(1)
(2)
Y=105 2-wire E&M/4-wire E&M Trunk
00-63: Trunk Route No.
0 : 2-wire E&M Trunk
1 : 4-wire E&M Trunk
•
(1)
(2)
Y=104 Polarity of E&M Trunk
00-63: Trunk Route No.
1 : E wire (Open), M wire (Open), Signal-
ing (Type V)
2 : E wire (Ground), M wire (Battery),
Signaling (Type I)
3 : E wire (Ground), M wire (Ground),
Signaling (Type V/Type II) NOTE 2
[Series 3300 software required]
START
CM10
CM14
CM20
CM30
CM35
A
TIE LINES
