– 762 – NWA-008845-001 Rev.5.0
32ch2001.fm
HOTEL SYSTEM SPECIFICATIONS
• PMS/SMDR Interface via RS-232C/Hotel Printer Interface
NOTE: For the port 1 and port 3 of AP00-B card with AP00 program, data speed cannot be set to 9600
bps.
ITEM
SPECIFICATIONS
PMS/SMDR INTERFACE HOTEL PRINTER INTERFACE
Physical Interface RS-232C RS-232C
Synchronization Asynchronous Asynchronous
Protocol IMS Procedure -
Transmission Speed 1200/2400/4800/9600 bps
(for PN-AP00-B with AP00 program)
NOTE
300/1200/2400/4800/9600/19200 bps
(for PN-AP00-B/PN-AP00-D with
MRCA program)
1200/2400/4800 bps
I/O port No. 0-3 port of AP00-B/AP00-D card No. 0/3 port of AP00-B/AP00-D card
JULY/01/2006
HOTEL SYSTEM SPECIFICATIONS
