CALL WAITING INDICATION-UCD
To provide the LEDs on the D
term
for UCD Call Waiting Indication:
PROGRAMMING
DESCRIPTION DATA
Assign the incoming call to queuing mode
when all UCD stations are busy.
(1)
(2)
212
1: Queuing
Specify the maximum number of queuing in
each UCD group for controlling call waiting
lamp of a D
term
.
(1)
(2)
15
01-99 : 1 call-99 calls
NONE : 1 call
NOTE: Depending on the number of queuing station/trunk, lamp indication pattern on a D
term
is
different as shown below:
N=Number of queuing station/trunk
Assign the Call Waiting Indication LED to the
required D
term
.
•
(1)
(2)
Y=00
My Line No. + + Key No.
F1280-F1295: UCD Group 0-15
START
CM08
CM42
CONDITIONS LAMP INDICATION
2nd Data=01 Steady on red irrespective of number of queuing station/trunk
1
≤N<2nd Data (2nd Data≠01) Steady on red
2nd Data
≤N (2nd Data≠01) Flashing red
CM90
,
END
UNIFORM CALL DISTRIBUTION (UCD)
CALL WAITING INDICATION-UCD
