DIRECT STATION SELECTION/BUSY LAMP FIELD (DSS/BLF) CONSOLE
PROGRAMMING
DESCRIPTION DATA
Assign the DSS Console number to its associ-
ated LEN.
(1)
(2)
000-763: LEN
DSS Console No.
For PIM0/1 : E100-E107
For PIM2/3 : E108-E115
For PIM4/5 : E116-E123
For PIM6/7 : E124-E131
Assign the DSS Console number to its associ-
ated LEN.
[Series 3200 R6.2 software required]
NOTE: When using Series 3500 software or
later, for the FP No. 00-03 of MP
built-in FP/FP card of Main Site
and MP built-in FP of Remote Site,
the DSS console number (E100-
E131) can be assigned without limit
as shown right.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
DSS Console No.
For FP No. 00 : E100-E107
For FP No. 01 : E108-E115
For FP No. 02 : E116-E123
For FP No. 03 : E124-E131
Assign a single-line station, D
term
, or
DESKCON to work in conjunction with the
DSS Console.
(1)
(2)
00-31: DSS Console No. (Last two digits of
E100-E131 assigned by CM10/
CM14)
X-XXXXXXXX: Station No./My Line No.
of D
term
E000-E007 : ATTCON No.
Assign the station and trunk numbers, as need-
ed, to the keys on each DSS Console.
(1)
(2)
DSS Console No. (00-31) + + DSS Key
No. (00-59)
X-XXXXXXXX: Station No.
D000-D255 : Trunk No.
Assign a Do Not Disturb and Message waiting
function key on each DSS Console, if needed.
(1)
(2)
DSS Console No. (00-31) + + DSS Key
No. (57-59)
F1049: Message Waiting Set/Reset
F1053: Do Not Disturb Set/Reset
When providing Do Not Disturb or Message
Waiting function key, assign a changing Func-
tion key on each DSS Console.
(1)
(2)
DSS Console No. (00-31) + + DSS Key
No. (56)
F1052: Function Change
START
CM10
CM14
CM96
CM97
,
,
,
A
