Philips Sopho 2000 IPS - Caller ID-Station

– 190 – NWA-008845-001 Rev.5.0
32ch1003.fm
CALLER ID-STATION
PROGRAMMING
DESCRIPTION DATA
Assign the Caller ID sender (SDT) card num-
ber to the required LEN.
NOTE: The SDT card number must be as-
signed to the first LEN (Level 0) of
each LT slot. Level 1-3 remain
“NONE”.
(1)
(2)
000-763: LEN
C200-C203: SDT Card No.
Assign the station number of an analog tele-
phone for Caller ID-Station to the required
LEN.
NOTE: The station number must be as-
signed to the first LEN (Level 0), the
second LEN (Level 1), the third LEN
(Level 2) and the fourth LEN (Level
3) of each LT slot.
(1)
(2)
000-763: LEN
X-XXXXXXXX: Station No.
Assign the Caller ID sender (SDT) card num-
ber to the required LEN.
[Series 3200 R6.2 software required]
NOTE: The SDT card number must be as-
signed to the first LEN (Level 0) of
each LT slot. Level 1-3 remain
“NONE”.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
C200-C203: SDT Card No.
Assign the station number of an analog tele-
phone for Caller ID-Station to the required
LEN.
[Series 3200 R6.2 software required]
NOTE: The station number must be as-
signed to the first LEN (Level 0), the
second LEN (Level 1), the third LEN
(Level 2) and the fourth LEN (Level
3) of each LT slot.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
X-XXXXXXXX: Station No.
Assign the purpose of the Caller ID sender. •
(1)
(2)
Y=01
02
0: Caller ID-Station
START
CM10
CM14
CM04
A
CALLER ID-STATION
