HOTLINE-INSIDE/OUTSIDE
PROGRAMMING
For internal Hotline:
DESCRIPTION DATA
Assign the Hotline station to the required sta-
tions.
•
(1)
(2)
Y=03
X-XXXXXXXX: Station No.
04: Hotline Station
Set up the Hotline pair. Bidirectional Hotlines
should be assigned as follows:
NOTE 1: There is a maximum of 100 assign-
ments for Hotline destination. If in-
ternal bidirectional Hotline calling
is required, two assignments (one
for each direction) must be made. A
maximum of 50 bidirectional Hot-
lines can be assigned.
•
(1)
(2)
Y=00-99 Hotline Pair No.
0: Calling Side
X-XXXXXXXX: Station No. /Data Sta-
tion No. assigned by
CM12 Y=03
(1)
(2)
1: Called Side
X-XXXXXXXX: Station No. /Data Sta-
tion No.
E000-E007 : Attendant Console No.
NOTE 2: Do not assign station number
with first digit “0”.
Specify the result of a Switch Hook Flash on
each Hotline station.
To allow Hotline stations to transfer a call or
access a feature, set the data to “0”.
(1)
(2)
057
0 : Special Dial Tone
1 : Attendant Recall
START
CM12
CM52
Hotline Pair No. Calling Side Called Side
00
01
Station A
Station B
Station B
Station A
CM08
END
