LINE EQUIPMENT NUMBER (LEN)
The system allows all the CM10 setting data to be also assigned by CM14 from Series 3200 R6.2. When
your system contains Series 3200 R6.2 or later software, we recommend you to assign station number,
trunk number and card number by CM14.
This manual explains the feature programming using CM10. For the feature programming using CM14,
follow the LEN assignment shown below.
• LEN assignment by CM14
Level 0
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6
Level 7
LT card accommodation position
number in Physical PIM/
Virtual station of D
term
IP
accommodation position in Virtual
PIM
XXZZZ
XXZZZ
XXZZZ
XXZZZ
XXZZZ
XXZZZ
XXZZZ
XXZZZ
(LTXX)
XX
ZZZ: Port Number of Physical PIM/
Virtual PIM (000-127)
: FP Number (00-59)
[For Series 3300 software or later]
XX
ZZZ: Port Number of Physical PIM/
Virtual PIM (000-127)
: FP Number (00-31)
[For Series 3200 R6.2 software or before]
LINE EQUIPMENT NUMBER (LEN)
