Philips Sopho 2000 IPS - Tie Line Tandem Switching

– 697 – NWA-008845-001 Rev.5.0
32ch1011.fm
TIE LINE TANDEM SWITCHING
PROGRAMMING
HARDWARE REQUIRED
ODT card
DESCRIPTION DATA
Specify the combination of Trunk Routes al-
lowing the Tandem connection. The incoming
trunk route must provide a release signal for
the Tandem Connection. (See CM35 Y=05)
•
(1)
(2)
Y=0
XX ZZ
XX: 00-63: Incoming Trunk Route
ZZ : 00-63: Outgoing Trunk Route
0 : Allow
1 : Restricted
START
CM36
END
TIE LINE TANDEM SWITCHING
