INTRODUCTION
– 14 – NWA-008845-001 Rev.5.0
32ch0001.fm
PB (DTMF) RECEIVER NUMBER
A system with Series 3200 R6.2 software provides the MP built-in PB (DTMF) Receiver for a Remote Site
of Remote PIM over IP feature. For the Series 3200 R6.2 or later software, the DTMF Receiver card num-
ber is as follows.
• MP built-in DTMF Receiver in Main Site : E200 (This number is also used when a system is not
provided Remote PIM over IP feature.)
• 8RST card in Main Site : E201-E215 (This number is also used when a system
is not provided Remote PIM over IP feature.)
• MP built-in DTMF Receiver in Remote Site: E216-E230 (E216-E230 matches Remote Site number
01-15)
[For Series 3200 R6.2 software]
E216-E245 (E216-E245 matches Remote Site number
01-30)
[For Series 3300 software or later]
NOTE: When a system is not provided Remote PIM over IP feature or a system is a Main Site of Remote
PIM over IP feature, you can assign maximum four DTMF Receiver card numbers per FP (in-
cludes the number for MP built-in DTMF Receiver). For the Remote Site, MP built-in DTMF
Receiver can be used per Remote Site.
For CM45 setting data, DTMF Receiver number in Series 3200 R6.2 or later is as shown below.
• CM45 Y=0 (Make Busy)
(1) XX Z (DTMF Receiver No.)
XX: 00-30 (MP Built-in DTMF Receiver/8RST Card No.)
[For Series 3200 R6.2 software]
00-45 (MP Built-in DTMF Receiver/8RST Card No.)
[For Series 3300 software or later]
Z : 0-3 (Circuit No.)
(2) 0 : Make busy
1 : In service
• CM45 Y=1 (DTMF Receiver for incoming call from Tie Line/DID)
(1) XX Z (DTMF Receiver No.)
XX: 00-30 (MP Built-in DTMF Receiver/8RST Card No.)
[For Series 3200 R6.2 software]
00-45 (MP Built-in DTMF Receiver/8RST Card No.)
[For Series 3300 software or later]
Z : 0-3 (Circuit No.)
(2) 0 : Only for incoming call from Tie Line/DID
1 : For both DTMF station and Tie Line/DID
PB (DTMF) RECEIVER NUMBER
