– 620 – NWA-008845-001 Rev.5.0
32ch1010.fm
SYSTEM CAPACITY
(1) MP Built-in SMDR on RS-232C
• The maximum of trunk calls simultaneously: 255 trunk calls
• The maximum of call record: 1024 call record
(2) MP Built-in SMDR on IP
• The maximum of trunk calls simultaneously: 255 trunk calls
• The maximum of call record: 1024 call record
(3) SMDR with AP00
Buffer Memory Capacity within AP00 card can store the following number of call information
temporarily.
• PN-AP00-B with AP00 program
• PN-AP00-B/PN-AP00-D with MRCA program
Amount of Call Records number of CMD003 1st data 23, 24, 25, 26, 28, 29, 30
No EXPMEM on AP00 is provided EXPMEM on AP00 is provided
When CMD001>179
is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
When CMD001>179
is set to 1
(Center Office of
Centralized Billing-
CCIS)
When CMD001>179
is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
When CMD001>179
is set to 1
(Center Office of
Centralized Billing-
CCIS)
1600 800 27000: When CMD003>28 is set to 0
(Call Record for CIS is not provided)
26000: When CMD003>28 is set to other than 0
(Call Record for CIS is provided)
Amount of Call Records number of CMDD02 1st data 0, 1, 2
No EXPMEM on PN-AP00-B
is provided
EXPMEM on PN-AP00-B/PN-AP00-D
is provided
CMDD00>3 is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
CMDD00>3 is set to 1
(Center Office of
Centralized Billing-
CCIS)
CMDD00>3 is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
CMDD00>3 is set to 1
(Center Office of
Centralized Billing-
CCIS)
2620 1310 23580 22270
JULY/01/2006
STATION MESSAGE DETAIL RECORDING (SMDR)
SYSTEM CAPACITY
