– 191 – NWA-008845-001 Rev.5.0
32ch1003.fm
By the following programming, the Caller ID sender can be set in make busy or in service status.
DESCRIPTION DATA
Specify the calling party information which is
sent to the analog telephone for Caller ID-
Station.
•
(1)
(2)
Y=20
X-XXXXXXXX: Station No.
0: Calling Party Number
1: Calling Party Number and Calling Party
Name
Specify whether the calling station number is
sent to the analog telephone for Caller ID-
Station when an internal call is terminated.
(1)
(2)
507
0: Not sent
1: To send
To call back from the analog telephone for
Caller ID-Station, assign the access code to be
added to the calling station number when an
internal call is terminated.
•
(1)
(2)
Y=00
8
X-XXXX: Access Code to be added
(Maximum 4 digits)
X: 0-9, A (*), B (#)
Restrict One hit ringing for Call Forwarding-
All Calls. (To restrict all stations in the system)
(1)
(2)
266
0: Restricted
Assign Service Restriction Class C to each sta-
tion. (To restrict per Station Class)
•
(1)
(2)
Y=07
X-XXXXXXXX: Station No.
00-15 : Service Restriction Class C
Restrict One hit ringing for Call Forwarding-
All Calls to Service Restriction Class C as-
signed by CM12 Y=07. (To restrict per Station
Class)
•
(1)
(2)
Y=81
00-15: Service Restriction Class C as-
signed by CM12 Y=07
0: Restricted
DESCRIPTION DATA
Assign the make busy condition of the Caller
ID sender.
•
(1)
(2)
Y=5
XX Z
XX: 00-03: SDT Card No. assigned by
CM10/CM14
Z : 0-3: Circuit No.
0 : Make busy
1 : In service
A
CM12
CM08
CM50
CM08
CM12
CM15
END
START
CM45
END
CALLER ID-STATION
To Next Page
