– 689 – NWA-008845-001 Rev.5.0
32ch1011.fm
DESCRIPTION DATA
When you use the ODT card for 2-wire E&M
trunk, set CM35 Y=100 to 14/15.
NOTE: When using Series 3600 software or
later, a reset of the MP card is not
required after this command is set/
changed.
When changing the data with online,
the data is valid after the trunk card
is unplugged and plugged in.
•
(1)
(2)
Y=100 Terminating and Balanced Network
Impedance
00-63: Trunk Route No.
14: 2-wire E&M Trunk (for regular)
15: 2-wire E&M Trunk (for long line)
NONE : For regular
Assign trunk route data to the trunk route num-
ber assigned by CM30 Y=00.
•
(1)
(2)
Y=00 Kind of Trunk Route
00-63: Trunk Route No. (01/02)
04: Tie Line
•
(1)
(2)
Y=01
00-63: Trunk Route No. (01/02)
< Incoming > < Outgoing >
2 : DP-10PPS DP-10PPS
4 : DTMF DTMF
7:DTMF/DP DTMF
•
(1)
(2)
Y=02 IC/OG
00-63: Trunk Route No. (01/02)
1: Incoming trunk
2 : Outgoing trunk
3 : Bothway trunk
•
(1)
(2)
Y=04 Answer Signal from distant office
00-63: Trunk Route No. (01/02)
2 : Arrive
7: Not arrive
•
(1)
(2)
Y=05 Release Signal from distant office
00-63: Trunk Route No. (01/02)
1 : Arrive
•
(1)
(2)
Y=08 Sending of Dial Pulse
00-63: Trunk Route No. (01/02)
3: Send
A
CM35
INITIAL
B
DECEMBER/02/2005
TIE LINES
To Next Page
