DESCRIPTION DATA
When an External Key for Day/Night Mode
change or Class of Service change is required,
assign the DK card to required LEN.
[Series 3200 R6.2 software required]
NOTE 1: The DK card number must be as-
signed to the first LEN (level 0) and
the third LEN (Level 2).
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
E900-E963 : DK Card No.
For FP No. 00: E900-E915
For FP No. 01: E916-E931
For FP No. 02: E932-E947
For FP No. 03: E948-E963
NOTE 2: Circuit No. 3 of E963 is used for
built-in External Key Interface of
MP card by setting CM61.
Specify ON/OFF condition for external relay/
external key on MP built-in DK00 card.
(1)
(2)
700
0 : ON (Ground Start)
OFF (Ground Off [Open])
1 : ON (Ground Off [Open])
OFF (Ground Start)
To provide external keys for Day/Night Mode
change or Class of Service change, assign a
Tenant number to the DK card.
•
(1)
(2)
Y=00
XX Z
XX: 00-31: DK Card No. assigned by
CM10/CM14 (E900-E963)
Z : 0-3: Circuit No.
633: MP Built-in External Key Interface
00-63: Tenant No.
Specify the Tenants to be handled by each AT-
TCON Group.
•
(1)
(2)
Y=0-3 ATT Group 0-3 assigned by CM60
Y=00
00-63: Tenant No.
0 : To handle
1 : Not handled
A
CM14
CM08
CM61
CM62
INITIAL
B
JULY/01/2006
TENANT SERVICE
