– 556 – NWA-008845-001 Rev.5.0
32ch1009.fm
DESCRIPTION DATA
Assign the temporary Service Restriction
Class A/B/C to be applied to each station after
the station class is changed.
•
(1)
(2)
Y=02
X-XXXXXXXX: Station No.
00-15 : Service Restriction Class A
•
(1)
(2)
Y=03
X-XXXXXXXX: Station No.
00-15 : Service Restriction Class B
•
(1)
(2)
Y=04
X-XXXXXXXX: Station No.
00-15 : Service Restriction Class C
Select the timing when the temporary service
class returns to proper service class.
(1)
(2)
258
0 : When called number has been dialed
1 : When station goes on hook
A
CM2B
CM08
END
PAD LOCK
