DESCRIPTION DATA
For a DP trunk, assign the type of signaling for
Outgoing and Bothway trunk routes to DP.
•
(1)
(2)
Y=01
00-63: Trunk Route No.
<Incoming> <Outgoing>
2: DP DP
Specify the DP Sender characteristics to match
the Central Office.
•
(1)
(2)
Y=23 DP Sender Inter Digital Pause
00-63: Trunk Route No.
0 : 300 ms.
1 : 400 ms.
2 : 500 ms.
3 : 600 ms.
4 : 700 ms.
5 : 900 ms.
6: 1100 ms.
7 : 800 ms.
•
(1)
(2)
Y=25 DP Sender Make Ratio
00-63: Trunk Route No.
0: 39 %
1: 33 %
•
(1)
(2)
Y=45 DP Sender Release Timing
00-63: Trunk Route No.
0 : 2 seconds
1 : 4 seconds
2 : 6 seconds
3 : 8 seconds
4 : 12 seconds
5 : 14 seconds
6 : 16 seconds
7 : 10 seconds
For a DTMF trunk, assign the type of signaling
for Outgoing and Bothway trunk routes to
DTMF.
•
(1)
(2)
Y=01
00-63: Trunk Route No.
<Incoming> <Outgoing>
7:DTMF/DP DTMF
A
CM35
B
DIAL CONVERSION
