DESCRIPTION DATA
STEP3: Assign the starting time for the Toll
Restriction and Route Pattern
number to the Time Pattern
number assigned by above Step 2.
Set the Starting Time as shown
below.
NOTE: Two times must be set. The first to
start Toll Restriction and the second
to stop it (or change it back).
•
(1)
(2)
Y=2000-2007 Time Pattern No. 0-7
HHMM (Time to Change)
HH : 00-23: Hours
MM: 00/30: Minutes
0000-0255: Route Pattern No. 000-255
If Tenant Pattern is required, set 1000-1015
(Tenant Pattern No. 00-15).
STEP4: Assign the TR Pattern number to
the Route Pattern number assigned
by Step 3.
•
(1)
(2)
Y=0000-0255 Route Pattern No. 000-255
1
XXX 00
XXX: 000-255: TR Pattern No.
STEP5: Assign the Trunk Restriction
Pattern number assigned by CM81
to the TR Pattern number assigned
by Step 4.
•
(1)
(2)
Y=5000-5255 TR Pattern No. 000-255
000
00-15 : Trunk Restriction Pattern No.
00-15
D
CM8A
END
CODE RESTRICTION
To Next Page
