NOTE 1: If the system data all clear is required before programming from a CAT, perform the following
operations:
1. Plug the DLC card into LT00 Slot of PIM0.
2. Connect the CAT to LEN000 at the MDF.
3. Set SW3 on the MP card to “B”.
4. Press SW1 (RESET Switch) on the MP card (System Data All Clear).
5. Set SW3 to “0” and press SW1.
6. Set the D
term
to CAT mode (Station number 300 is automatically assigned to the D
term
).
NOTE 2: If Password Service is activated, enter the predetermined password (assigned by CME9>0-7)
by CM03 before programming from a CAT.
+ 03 + + Password Level number (0-7) + + Password +
– “OK” will be displayed, if accepted.
– “DATA ERROR” will be displayed if the password is incorrect.
DESCRIPTION DATA
Assign the setting/changing of the password to
be allowed.
(1)
(2)
8
0 : Allowed
1 : Restricted
Assign a password to each Password Level. (1)
(2)
0-7: Password Level 0-7
X-X...X: Maximum 8 digits Password
CCC : Password clear
A password for Password Level 7 should be
assigned in advance because of providing the
password service by Function No. 9 of CME9.
The following passwords are not available.
“CCCCCCCC”
“FFFFFFFF”
The setting/changing of the password is avail-
able only when the second data of CME9>8 is
set to “0 (Allowed)”.
If CME9>8 is set to “1 (Restricted)”, “DATA
ERROR” is displayed when you set/change the
password.
Provide the system with Password Feature.
After setting this data, access to system
programming will be available with password
entry only.
(1)
(2)
9
0: Provided
A
CME9
END
ST DE DE EXE
DECEMBER/02/2005
CUSTOMER ADMINISTRATION TERMINAL (CAT)
